Construction & Engineering
Shop drawings built from the contract set.
Steel, ceramic tile and masonry shop drawings prepared from the engineer’s and architect’s contract documents, laid out so the fabricator and the installer can work from the same sheets.
What you get
Shop Drawings
- Structural and miscellaneous steel: members, connections, anchor bolts, embeds
- Ceramic tile: layout, patterns, transitions, movement joints, details
- Masonry: elevations, coursing, reinforcing, control joints, openings
- Submittal-ready PDF sheets plus native CAD files
- Revisions until the reviewer’s comments are closed
Shop drawings follow the contract documents. Design responsibility stays with the engineer or architect of record, and no structural design is performed by the submittal.
What we need from you
The contract drawings, The specifications, Approved product data, Any RFI responses.
How it works
Four steps. No surprises.
02Within one working day
A fixed price in writing.
Scope, fee and delivery date, confirmed before anything starts. Scope Check reviews are free.
03The work
Measured, built, checked.
Every quantity measured from your sheets. Every page tested on a phone before you see it.
04Delivered
Yours, and then supported.
Editable workbooks, marked-up sheets, a live site you control. Questions after delivery are part of the job.
Prices
Priced per job. Send the scope and the fee comes back in writing before any work starts. It only changes if the scope does.
Request a quote ↗See every published priceQuestions
Asked before the first job.
Do you stamp the drawings?
No. Shop drawings are reviewed and approved by the design team, not stamped by the detailer.
How do revisions work?
Reviewer comments are addressed and resubmitted. Revisions within the original scope are included.
Which file formats?
PDF for submittal, plus DWG. Other formats on request.
Start a project
Tell us what you are bidding or what you want to grow. A written price comes back within one working day.
